Features and benefits

• Uncompressed 8 bit video encoding, High-speed synchronous digital transmission technology
• Fiber optic transmission of one video signals on one fiber with RS485 data signals which may be one way with the video or optionally duplex.
• Super optical dynamic range, no adjustment needed
• Status indication for power supply, optical signal and video
• No electromagnetic interference, radio frequency interference and ground current
• Safe transmission guaranteed under poor electromagnetic environment
• Maximum tolerable link loss for single mode single fiber is 18db
• Range of up to 100km is possible with optional 1550nm operation
• Optional duplex operation over one fiber
• Video bandwidth of 6.5 MHz, SNR>63dB
• Radiation: EN50081-1, EN55022-B, CE, FCC
• Magnetic capacity: EN50130-4, EN50028-1
