Features

• Six TP switching ports with 10/100Mbps auto-negotiation and half-/full-duplex auto-sensing
• Every TP port can auto-detect MDI or MDI-X connection, no crossover cable is needed for switch/hub cascaded
• Two 100BaseFX port for fiber connection
• Support no VLAN or concentration VLAN settings
• Support long Ethernet frame up to 1522 bytes and 2 queues per port for QoS
• Operates at maximum packet filtering and forwarding rate, total bandwidth up to 800Mbps
• Support flow control to prevent packet loss
• 1x9 or SFP transceiver optional for optical interface ? pls note when order ?

Technical Specification

• Standards?IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX/FX
• Access Method?CSMA/CD, 10Mbps and 100Mbps
• Media Supported
• 10Mbps?Category 3,4,5 TP cable
• 100Mbps?Category 5 TP cable
• 100BaseFX?single mode or multi-mode fiber cable
• Number of Ports?Six RJ-45 MDI-X / MDI ports, Two 100Base FX port
• VLAN?Support No VLAN or Concentration VLAN
• Network Interface?Six 10/100TX ports and Two 100Base-FX fiber port
• Flow control?IEEE802.3x compliant for full-duplex, Back pressure flow control for half-duplex
• LED Indicator?Power, Link/Activity, FDX/Collision
• Power
• Requirement?100~240VAC, 50~60Hz
• Consumption?5W maximum
• Ambient Temperature?0~50°C
• Humidity?5~90%
• Dimensions?180*140*28mm (external power)
• Certification?FCC Part 15 Class A, CE Mark
