Features:

• Bayonet style housing for easy termination
• Epoxy and epoxy-less versions
• High precision alignment
• Low insertion and return loss and back reflection

Speclifications:

• PC , UPC or APC polishing
• Fiber Standard : Single Mode (ITU-T G.652) , Multimode (ITU-T G.651)
• Standard : Telcordia GR-326-CORE
• Cable diameter : 3.0mm or 2.0mm or 0.9mm
• Fiber type : 9/125μm , 62.5/125μm , 50/125μm or 10G
• Insertion loss : SM Less than 0.3dB , MM Less than 0.3dB
• Return loss : PC SM larger than 45 dB
  • UPC SM larger than 50 dB
  • APC SM larger than 60 dB
  • UPC MM larger than 20 dB
• Repeatability : Less than 0.2 dB
• Changeability : Less than 0.1 dB
• Operating temperature range : -40°C ~ 80°C
• Storage temperature range : -40°C ~ 80°C
